EG4 BrightMount Adjustable Cat1

EG4 BrightMount Adjustable Cat1 – Solar Ground Mount System

Durable, Adjustable, and Built for Serious Solar Installations

The EG4 BrightMount Adjustable Cat1 is a rugged, modular solar ground mount system designed to support up to four solar panels with exceptional stability and adaptability. Made from high-grade anodized aluminum alloy and stainless-steel hardware, this system is engineered to withstand the demands of both residential and commercial environments. Whether you're deploying in a remote off-grid location or a high-wind region, the BrightMount delivers both performance and peace of mind.

Adjustable Tilt Angles for Seasonal Optimization

The system offers five preset tilt angles—20°, 25°, 30°, 35°, and 40°—allowing you to adjust your panel orientation throughout the year for maximum solar exposure. This flexibility is ideal for installers and homeowners seeking to optimize energy production based on geographic location and seasonal sun position.

Engineered for Harsh Environments

With wind resistance up to 90 mph (40.4 m/s) and pressure endurance ratings of 1640.56 N/m² (windward) and 1456.22 N/m² (leeward), the BrightMount Cat1 system is built for longevity in challenging outdoor conditions. The anodized finish prevents corrosion, while the stainless-steel fasteners maintain integrity under stress and weathering.

Quick and Reliable Installation

Each kit comes complete with all required rails, end clamps, grounding components, and mounting hardware. The system is designed for efficient assembly with standard tools and includes a detailed checklist to streamline setup. Adjustable aluminum legs allow you to easily configure your array’s tilt during installation, and all grounding paths meet electrical safety standards for solar equipment.

What’s Included

• Rail system with adjustable legs and mounting brackets
• End clamps and mid clamps for securing up to four panels
• Grounding components for system-level bonding
• Fasteners, bracing, and hardware for structural support
• Detailed installation guide with safety and tool instructions

Installation Notes

The BrightMount Cat1 is designed for use with a concrete base foundation to ensure structural stability. Refer to the included manual for proper anchoring methods, angle adjustments, and safe panel handling procedures. Always follow PPE and team lifting guidelines, especially when managing large modules or remote deployments.

Why Choose EG4 BrightMount Adjustable Cat1?

EG4 combines structural engineering with installer-focused design to deliver a mounting system that’s flexible, fast to install, and built to last. Whether you're a solar contractor building out residential ground arrays or a DIY homeowner seeking robust mounting options, the BrightMount Cat1 offers a cost-effective and scalable solution backed by a name trusted in the energy storage and PV industry.
